Original (regular) Suzuki CHROME safety arches for Suzuki Intruder VZ1500 / VL1500 or Boulevard M90/C90 motorcycles.
These are the only arcs produced for this motorcycle that are installed in standard mounts! When developing these safety arcs, engineers took into account the weight and other features of the Suzuki Intruder VZ1500 / VL1500 or Boulevard M90 / C90 and optimized the design of the arcs for maximum protection of the motorcycle when falling at low and medium speed. Arcs are an additional option for this motorcycle model from the manufacturer and are considered its regular body kit.
Intruder VZ1500 / Boulevard M90 - all years;
Intruder VL1500 / Boulevard C90 - from 2013 and above.
A copy of the original stainless steel arcs:
In our own production, we have established the manufacture of an exact copy of the original Suzuki arches, but not of black metal, like the original, but of stainless steel! In addition to the fact that stainless steel arcs are completely maintainable and much lighter, they also do not spark when sliding, which makes them safe when spilling fuel.. Polished stainless steel is indistinguishable from chrome, and any damage to it is easily polished, which is not applicable to a chrome surface. You can order a copy of the original stainless steel arches at this link...
On the Intruder VZ1500 / Boulevard M90, you need to unscrew the front mounting bolts of the driver's footrest brackets, which will be used as fasteners for the upper part of both arches (just rearrange them). The lower brackets of the arches are superimposed on top of the previously unscrewed bolts and are attracted by elongated bolts that are supplied in the kit. Installation of arcs does not require any special skills and will take 5-10 minutes, without the need to involve specialists!
The installation of arcs on Intruder VL1500 / Boulevard C90 - from 2013 and above is not much different from the installation on M90 / VZ1500, but it has one nuance. You need to unscrew the front mounting bolts of the driver's footrest brackets, which will be used as fasteners for the upper part of both arches (just rearrange them). But the lower brackets of the arches, unlike the M90 / VZ1500, you do not put bolts on top of the previously unscrewed bolts, but insert them between the frame and the driver's footrest bracket! At the same time, you need to unscrew the rear bolts of the footrest brackets and install the supplied bushings between the frame and the bracket. Thus, the brackets of the footrests on both sides of the motorcycle will extend by 5mm due to the insertion of the brackets of the arches in front and due to the sleeve at the back. Installation of arcs does not require any special skills and will take 5-10 minutes, without the need to involve specialists!
Delivery is carried out throughout Russia, to the countries of the former Soviet republics and Europe. At your request, you can choose to send by regular mail, EMS or another transport company when approving the order. The cost of shipment is calculated upon receipt of information about the recipient's city and depends on the dimensions and weight of the cargo.
It is also possible to pick up the order from Pushkino, Moscow region or delivery by courier within the MKAD (subject to approval).
Learn more about payment and delivery...
After receiving the order, do not forget to leave your feedback.
