A copy of the standard safety arches made of POLISHED stainless steel for the Suzuki Intruder VZ1500 / VL1500 or Boulevard M90 / C90 motorcycle.

price: 35 550 р.

An exact copy of the original Suzuki safety arches for Suzuki Intruder VZ1500 / VL1500 or Boulevard M90/C90 motorcycles.

Specification:
The arcs are made in our own production from polished stainless steel and are an absolutely exact copy of the standard safety arcs for Suzuki Intruder VZ1500 / VL1500 or Boulevard M90 / C90 motorcycles.

The only difference between our production arcs and regular ones is the material, but not to the detriment of the product, but only to improve its qualities!

Advantages of a copy of regular arcs:

  • stainless steel does not spark when rubbing against asphalt, unlike ordinary metal from which regular safety arcs are made;

  • the gloss of the polished surface of stainless steel is indistinguishable from chrome, it is not afraid of rust, chips, "road sandblasting" and, in case of any damage, it is perfectly polished and restored to its original state, unlike electroplating of standard arcs, which can no longer be restored;

  • in almost any deformation, stainless steel arcs are restored to the state of new ones.

Compatibility:

  • Intruder VZ1500 / Boulevard M90 - all years;

  • Intruder VL1500 / Boulevard C90 - from 2013 and above.

Installation:

  • On the Intruder VZ1500 / Boulevard M90, you need to unscrew the front mounting bolts of the driver's footrest brackets, which will be used as fasteners for the upper part of both arches (just rearrange them). The lower brackets of the arches are superimposed on top of the previously unscrewed bolts and are attracted by elongated bolts that are supplied in the kit. Installation of arcs does not require any special skills and will take 5-10 minutes, without the need to involve specialists!

  • The installation of arcs on Intruder VL1500 / Boulevard C90 - from 2013 and above is not much different from the installation on M90 / VZ1500, but has one nuance. You need to unscrew the front mounting bolts of the driver's footrest brackets, which will be used as fasteners for the upper part of both arches (just rearrange them). But the lower brackets of the arches, unlike the M90 / VZ1500, you do not put bolts on top of the previously unscrewed bolts, but insert them between the frame and the driver's footrest bracket! At the same time, you need to unscrew the rear bolts of the footrest brackets and install the supplied bushings between the frame and the bracket. Thus, the brackets of the footrests on both sides of the motorcycle will extend by 5mm due to the insertion of the brackets of the arches in front and due to the sleeve at the back. Installation of arcs does not require any special skills and will take 5-10 minutes, without the need to involve specialists!

Non-alternative advantages of stainless steel arcs on the example of the "MADMAX" series for Suzuki Intruder and Boulevard motorcycles.



Delivery:
Delivery is carried out throughout Russia, to the countries of the former Soviet republics and Europe. At your request, you can choose to send by regular mail, EMS or another transport company when approving the order. The cost of shipment is calculated upon receipt of information about the recipient's city and depends on the dimensions and weight of the cargo.

It is also possible to pick up the order from Pushkino, Moscow region or delivery by courier within the MKAD (subject to approval).

Learn more about payment and delivery...

After receiving the order, do not forget to leave your feedback.

Article 00639
